FT RG PM Fused Combiner
Description
FT RG PM Fused Combiner
The Polarization Maintaining Fused RG Combiner is manufactured by using advanced technology and polarization maintaining fiber to enable the red and green light to be combined. They offer low excess loss, small size, high extinction ratio, high return loss, and excellent environmental stability.
|
Specifications |
||
|
Parameter |
Unit |
Value |
|
Center Wavelength (λc) |
nm |
532(G)/635(R) |
|
Typ. Insertion Loss, λc |
dB |
1 |
|
Max. Insertion Loss, λc |
dB |
1.5 |
|
Min. Extinction Ratio |
dB |
18 |
|
Thermal Stability |
dB/℃ |
≤ 0.005over -5 to +70 °C |
|
Min. Return Loss |
dB |
55 |
|
Min. Directivity |
dB |
55 |
|
Max. Optical Power |
mW |
300 |
|
Fiber Type |
Nufern PM 460-HP fiber |
|
|
Operating Temperature |
℃ |
-40 to +75 |
|
Storage Temperature |
℃ |
-40 to +85 |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
