拉錐分路器-1×3

產品介紹

拉錐分路器-1×2

產品介紹

拉錐分路器-M2×2

產品介紹

MEMS 1×N 光開關

產品介紹

MEMS VOA

產品介紹

MEMS VOA is a precise and adjustable voltage-driven optical component. The key part of the component is MEMS chip; driving voltage produces electrostatic force to drive the micro-mirror on the chip, then to adjust output optical power. It has excellent features such as compact dimension, low power consumption, fast responding, anti-shock, low WDL as well as low PDL. It is successfully applied in military project. It meets reliability standard of Telcordia 1221.
MEMS VOA has 2 series: fast responding series and low voltage driving (LOWO) series. Each series has variable models like single wavelength, dual wavelength, and polarization-maintaining. We could also develop and produce other MEMS VOA as customers’ requirement.

光波導色散延遲線

產品描述：
成都北億纖通科技有限公司的單片集成色散光延時芯片及組件,是基于厚膜 SOI 硅光子技術、將硅基波分復用器和硅波導延時回路單片集成的創新型產品。
它具有 0.5ps 以下的超高延時精度，單片集成使其尺寸比傳統器件小 1 個數量級,同時解決了多個光耦合界面引入 的損耗、可靠性問題，是針對多波長光源的色散光控相控陣系統的理想光延時產品。
