Part Number：FT-45-TOSA-1XX0-2-SM

Product Description: The Pluggable TO56 CWDM series laser diodes are 1.27μm~1.61μm Multiple Quantum Well (MQW) structured distributed-feedback(DFB) laser modules. These laser diodes are built in a pluggable TO56 package with monitoring PIN-PD for fiberoptic communication systems. These modules are ideally suitable for 2.5Gbps transmission applications. The products are Telcordia GR-468 qualified, and in compliance with RoHS requirement.

Applications:
█ Telecommunication transceivers
█ Datacom transceivers
█ Fiberoptic sensors

Features:
█ CWDM laser diode module
█ Signal rate up to 10/25Gb/s
█ LC receptacle TOSA package
█ High output power（>2mW)
Reliability: Telcordia GR-468. RoHS

工作溫度（多種溫度級別可選）:
商用級：0~+7度
擴展級：-10~+80度
工業(yè)級：-40~+85度
軍品級：-55~+85度

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
