2.5Gb/s PECL 單模雙纖光收發一體模塊
2.5Gb/s PECL SINGLE MODE DUPLEX FIBERS OPTICAL TRANSCEIVER
特點:
● SC/FC/ST 或尾纖型光接口,單模雙纖光收發一體模塊
● +3.3V /+5V 供電
● 接口電平兼容標準 PECL 電平
● 標準 1×9 管腳封裝,引腳配置與 Multisource 協議兼容
● 發射器件可選用 1310nm 的 FP 激光器或 1550 DFB 激光器
● 接收采用平面結構 InGaAsP PIN 探測器
Features:
● SC/FC/ST receptacle optical interface and pigtail optical interface
● Single mode Duplex fibers optical transceiver
● +3.3V /+5V Power Supply
● Standard PECL data output with signal detect indication
● Multi-sourced 1×9 package
● High quality 1310nm MQW-FP LD/ 1550nm DFB LD
● Receiver has a planner InGaAsP PIN
應用:
● 2.5Gb/s 及以下速率的光纖傳輸系統,如 SDH 系統、數字視頻光端機等。
Applications:
● Applied to optical fiber transmission systems,such as SDH and digital video optical terminal devices with bit
rate up to 2.5Gbps
6 產品型號:FT-61-M392x-31
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
