100G QSFP28 CLR4 DML CWDM4 2km光收發模塊

產品描述
100G QSFP28 CLR4光收發模塊用于數據中心的中長距離互連，符合100G CLR4 MSA規范，同時兼容100G以太網和InfiniBand EDR傳輸協議。該產品內置一對4通道CWDM MUX和DEMUX，中心波長分別為1271nm、1291nm、1311nm和1331nm，使用一對單模光纖傳輸，距離最高可達2km或10km（無需開啟FEC）。

產品特點：
● 采用QSFP28可熱插拔封裝的全雙工收發一體模塊
● 4通道非制冷型CWDM DML和PIN
● 符合QSFP28 MSA和100G CLR4 MSA規范
● 兼容100G以太網和InfiniBand EDR傳輸協議
● 每通道傳輸速率最高可達25.78125Gbps
● 使用1對單模光纖傳輸，距離最高可達2km或10km（無需開啟FEC）
● 功耗小于3.5W
● 雙LC光口
● 商業級和工業級的工作溫度范圍可選
● 電源電壓3.3V
● 符合RoHS環保標準（無鉛）

產品參數

訂購信息

北億纖通 | F-tone Networks

企業郵箱：sales@f-tone.com
企業網站：www.f-tone.com
企業網站：mpgyk.cn
企業電話：028-85255257
企業傳真：028-85977702

本產品為FT-Y1系列，僅展示部分參數，如有需要，請聯系我們。
注：本產品有全國產化型號可選

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
