該模塊為 10/100/1000 BASE-T電口 SFP收發器，是高性能、低成本的模塊符合IEEE802.3-2002和IEEE802.3ab中規定的千兆以太網和1000BASE-T標準，它支持1000Mbps數據速率，通過非屏蔽雙絞線5類電纜傳輸距離可達到100米
該模塊支持具有5電平脈沖幅度調制（PAM）信號的1000 Mbps全雙工數據鏈路，電纜有四對線，每對線的符號速率為250Mbps。該模塊提供標準的符合SFP MSA的串行ID信息，可通過2線串行CMOS以A0h地址訪問EEPROM協議。物理IC也可以通過地址ACh處的2線串行總線訪問。

產品特點
● 傳輸速率1.25Gbps；
● 支持熱插拔；
● 低損耗；
● 緊湊RJ45連接器；
● EEPROM包含產品信息；
● 單3.3V 電源輸入；
● I2C 訪問；
● 10/100/1000 BASE-T operation in host
● systems with SGMII interface；
● SFP封裝；
● 符合RoHS標準

產品應用
● 1.25 Gigabit Ethernet over Cat 5 cable
● Switch/Router to Switch/Router Link

注：本產品有全國產化型號可選
